| Model | 단위 | L/S-250D(290) |
|---|---|---|
| Sash height (FH) | mm | 1190 to 3090 |
| Sash width (FB) | mm | 720 to 3350 |
| Sash weight | kg | max. 250 |
| Backset | mm | 27.5 |
| Sash thickness | mm | 56, 66 or 68 |
| Handle position | ||
| Sash height (FH) 1190 to 1590 | 410 | |
| Sash height (FH) 1591 to 1790 | 710 | |
| Sash height (FH) 1791 to 3090 | 1010 | |
| Gear size | mm | 170, 190, 200, 230, 260 or 300 |
| PROFILE MATERIAL | P.V.C | ALUMINUM | WOOD |
|---|---|---|---|
WIDTH(L)=22mm, HEIGHT(H)=42.5mm |
LS-250D | LS-250DA | LS-250DW |
